Product Code:
DDP-1/2
POLYPROPYLENE DOUBLE DIAPHRAGM PUMP
WITH 53LITRE/MINUTE FLOW RATE & MAX AIR
PRESSURE OF 690kPa (100psi) - 1/2 BSP
|
|
|
|
Please enter a valid quantity |
|
|
|
 |
|
|
Product Description
Not Suitable for Acid, Alkali and Other Corrosive Liquids.
Specifications
Product: Diaphragm Pump
Type: Double Diaphragm
Operation Type: Air-operated
Model: Qbk-15
Body Material: Cast Iron
Inlet Port: 1/2 Inch (12.7 Mm)
Outlet Port: 1/2 Inch (12.7 Mm)
Air Inlet Size: 1/4 Inch (6.35 Mm)
Gas Nozzle: 0.32 Inch (8 Mm)
Max Flow Rate: 2 M3/H (12 Gpm)
Suction: 0-5 M (0-16.4 Ft)
Max Head: 69 M (226.4 Ft)
Max Psi: 115 Psi
Package Size: 30 X 28 X 20 Cm (11.81 X 11.02 X 7.87 Inch) Gross Weight: 6.5 Kg (14.33 Lbs)
|
